Ultrasonic rolling welding machine

Features

Bilateral synchronous ultrasonic rolling welding;
Compatible with different sizes of glass and version switching servo control for one click switching, with manual adjustment for rectification;
Compatible with aluminum/copper strip welding;
The position of components are rectified with cylinder, with precise positioning and quick replacement;

Datasheet

Performance

Meeting the production demand for components with length of 2000mm-2300mm and width of 900mm-1200mm;
Tact time : 40s;
Distance from the busbar to the outer border: 0-20mm adjustable;
Welding position accuracy of busbar： ± 0.3mm;
Refueling time ≤ 3min.

Paramete

Equipment size: 3054mm * 2200mm * 2000mm (excluding tricolor lights).
