Features
Compact layout, can be integrated into existing production lines.
Compatible with various common types of j-boxes such as single and triple J-boxes, with convenient type switching.
Incorporates standard quality inspection functions after cover closing.
Large buffer capacity for cover storage, easy loading.
Optional components that meet UL/CE standards.
Optional adhesive curing inspection function
Specifications
| Item | Value | ||
| Compatible module type | Single J-box | Half-cell, G2G triple J-box | Shingling |
| Compatible module size | length: 1600-2500(mm); width: 900-1400(mm) | ||
| Cycle time | 14s | ||
| Number of J-box cover caches | ≥4h | ||
| J-box cover feeding method | Vibration feeder | ||
| Pre-sealing Adhesive Inspection Function | Curing quality & potting quality | ||
| Dimension(L x W x H) | 3000 x1800 x 2450 (mm) | ||
| Weight | 2000kg | ||
| Transportation height | 950±30mm | ||
| Feeding method | (LEL) | ||
| Utilization rate | 95% (VDI 3423) | ||
| Noise | Max 70dB | ||
| Power requirement | AC 3 phase, 380V/N/PE, 50Hz,15KVA | ||
| CDA | 0.4-0.6(MPa)，one drop，400L/min | ||
| Change time | 2h | ||
| PLC | Inovance | ||
