Features
Suitable for all current mainly module types.
Can base on different panel type and cell spacing to install different J-Box.
High speed, stability and compact layout
Simple and flexible operation with using removable teach pendant.
High degree of standardization and modularity, compatible with various J-Boxes.
Specifications
| Item | Value |
| Compatible module type | Glass-back sheet/G2G/Half-cell/Shingling |
| Compatible module size | length: 1600-2500(mm);width:900-1400(mm) |
| Material feeding method | Positive & Negative Electrode Frame Incoming / Intermediate Shaker incoming |
| J-Box grabbing method | Clamping jaw |
| Cycle time | 14s |
| Dimension(L x W x H) | 4940*2000*2500(mm) |
| Weight | 4t |
| Transportation height | 950±50 mm |
| Utilization rate | 95%(VDI 3423) |
| Noise | ≤75dB |
| Power requirement | AC 3 phase, 380V/N/PE, 50Hz,20KVA |
| CDA | 0.4-0.6Mpa，one drop，400l/min |
| Change time | 1h |
| PLC | Inovance |
| HMI | Inovance |
