Functionality
Sheet cutting accuracy: ±1mm
Punching accuracy: ±0.5mm
Cycle time: <14s
Noise: <70dB
Label material: compatible with materials such as PER, synthetic
paper, PE, PVC, PP, etc
Barcode size: length 40-60(mm): Width 6-12(mm)
Barcode detection: Check if the barcode is clearly printed and its consistency with incoming glass barcode. After the busbar code is printed, detect whether the barcode is crooked or damaged
Features
Compatibility with multiple module sizes, and a fast swap servo alignment system.
Insulation block cutting combined with punching function with a feeding buffer conveyor makes possible material replacement non stop.
The visual system detects the status of small blocks and ribbons by calculating the offset value, and arranges them using a four axis robotic arm.
Auto barcode labelling function with visual system for checking how the barcode is well attached.
Specifications
| Item | Value |
| Compatible module size | width: 990-1450(mm); length: 1640-2550(mm) |
| Power requirement | AC380V+5%，3P+1N+1PE，16A，50/60Hz |
| Power | 5kW |
| Air pressure | 0.5-0.7(MPa) |
| Dimension(L x W x H) | 4200*2200*2100(mm) |
| Weight | 2500kg |
