Functionality
The cutting knife moves together with the material pulling and transferring, the fastest cycle is 13s.
Intelligent correction system automatically corrects the positioning of the film, laying accuracy ±1.5mm.
High efficiency automatic roll changing, changing time less than 30s without stopping.
Features
Automatic correction of the film/backsheet laying deviation.
Automatic hot melt device, material change without stopping.
Servo-controlled alignment of glass edges, one-click switching between different modules.
Specifications
| Item | Value |
| Cutting accuracy | ±1.5mm |
| Cycle time | 13s |
| Compatible module size | length: 1650-2550(mm); width: 990-1450(mm) |
| Power requirement | AC380V+5%，3P+1N+1PE，32A，50/60Hz |
| Power | 8kW |
| Air pressure | 0.5-0.8(MPa) |
| Noise | <70dB |
| Dimension(Lx H x W) | 6250*2750*2000(mm) |
| Weight | 3500kg |
