Functionality
Fast cycle time, the cycle time of single string is 2.5s.
The camera has wide field of vision and the switching time is faster.
Better docking compatibility, can be docking more models of stringer.
Features
Realize visual positioning and automatic high-speed layup of strings.
Realize the functions of string layout, string turnover (optional), lead cutting (optional), string repair feeding and etc.
Can meet customer requirements of different cell string version, can be one-click switched.
Glass servo alignment, one-click switching of different modules.
Specifications
| Item | Value |
| Layup accuracy | ±0.3mm |
| Glass positioning accuracy | ±1mm |
| Cycle time | ≤30s(12series) |
| Compatible module size | length: 1650-2520(mm);width: 1010-1410(mm) |
| Power requirement | AC380V±5%，3P+1N+1PE，32A，50/60HZ |
| Power | 18kw |
| Air pressure | 0.5-0.7(MPa) |
| Noise | ≤70dB |
| Dimension(L x W x H) | 4020*3160*2560(mm) |
| Weight | 4500kg |
