Functionality
Through vision and servo system for deviation correction, high accuracy
The scraping mechanism from the middle to the outside synchronous scraping, high efficiency, scraping effect is good.
Four-point hot melt positioning to ensure that the transmission process does not produce secondary offset after correction.
Can be applied to various types of deviation, and the correction size range is large.
Features
Automatic correction of 1st adhesive film and glass laying deviation,
Realize the functions of film scraping and hot spot positioning.
Glass servo alignment, one-click switching of different modules.
Specifications
| Item | Value |
| Correction accuracy | ±1mm |
| Cycle time | ≤15s |
| Compatible module size | length: 1650-2550(mm);width: 990-1450(mm) |
| Power requirement | AC380V±5%，3P+1N+1PE，32A，50/60Hz |
| Power | 4.5kw |
| Air pressure | 0.5-0.8(MPa) |
| Noise | ≤70dB |
| Dimension(L x W x H) | 3530*1920*1885(mm) |
| Weight | 2000kg |
