Functionality
Module positioning accuracy: ±1mm
(the positioning is normalized without vibration)
Storage quantity of support bars: 200pcs
(compatible with double support bar modules)
Features
The overall structure is composed of a module alignment and conveying unit, a support bar storage and feeding unit, and a manipulator placement system.
The modules can be in and out at the same time, improving cycle time.
Double feeding system to increase the storage quantity of support bars.
Touch screen interface, switch module specifications, manual operation, alarm information and other parameter settings.
Specifications
| Item | Value |
| Compatible module size | length: 1650-2550(mm); width: 980-1650(mm) |
| Cycle time | ≤18s |
| Air pressure | 0.5-0.7(MPa) |
| Air consumption | 400L/min |
| Power | 5kW |
| Dimension(LxWxH) | 3400*2570*2300(mm) |
| Weight | 1800kg |
