Functionality
Module positioning accuracy: ±1mm
Cycle time: <23s
Alignment: four side alignment
Label position deviation: ±1mm
Change over time: < 3min
Fragment rate: ≤0.05%
Operation mode: Auto/ Manual
Noise level: ≤60dB
HMI: Chinese/ English mode
Yield:>98.5%
Features
The overall structure consists of transportation correction, suction labeling, labeling, and vacuum system.
Servo motor drives the labeling mechanism, high speed and high precision.
The suction and labeling system is delivered by a screw and timing belt. Accurate and fast suction and labeling. A compression spring for buffering when labeling.
Rolling the bar code and brand name with the roller to ensure that bar code and brand name are firmly attached to the module.
Specifications
| Item | Value |
| Model | SC-AL26-CS-01 |
| Compatible module size | 长length: 1640-2400(mm);宽 width: 950-1400(mm) |
| Cycle time | ≤23s |
| Air pressure | 0.5-0.7(MPa) |
| Power | 2.5kw |
| Dimension(L x W x H) | 3400*2100*1700(mm) |
