Functionality
Normal, half-cell, MBB fragmentation rate: ≤0.04%
Compatible cell specifications: 60 half-cell/72 half-cell/MBB half-cell
High temperature cloth changing frequency: ≥11 hours/time
Vision system: incoming material inspection, guiding positioning,final product inspection
Visual accuracy: ≤+0.1mm
Conveying direction: horizontal conveying
Mechanical positioning: servo or cylinder alignment
utilization rate: >99%
Ambient temperature: 15℃-30℃
Environmental humidity: 5%-75% (no dewfall)
Features
Compatibility with multiple module sizes alongside fast change-over servo alignment system.
A reliable vision system for detecting the status of incoming material guiding positioning process and inspecting finished products.
The motion unit is driven by servo motor with high speed, high precision, stable and reliable.
Auto lCB lead bending, Teflon patch or tape placement. (choose either of them as needed) and back sheet barcode attaching.
The three leads bound simultaneously in 14 seconds, effective and efficient.
Flexible contact between servo control and products ensures sound safety standards.
Over 99.5% of yield rate in taping and bar code labelling that is stable and reliable and labor-saving.
Specifications
| Item | Value |
| Compatible glass size | Long side: 1600-2500(mm)
Short side: 900-1500(mm) |
| Cycle time | ≤16s |
| Power | ≤7.5kW |
| Power requirement | AC380V±5%, 3P+1N+1PE, 20A, 50/60Hz |
| Air pressure | 0.6-0.8(MPa) |
| Air consumption | 200L/min |
| Noise | ≤75dB |
| Weight | 2500kg |
| Dimension(L x W x H) | 3700*2200*2100(mm) |
