Functionality
Guided by the visual system, the machine can automatically clamp the frame.
Under normal circumstances, 8 frames can be gripped at one time, and if there is a big gap between them, the frames can be captured several times in ways that reduce manual intervention.
The visual system is designed to detect NG frames.
The machine with buffer capacity of 70 sets of frames has the potential to feed 4 frames at one time to facilate next work station.
This equipment promises to make the assembly line more automated thus laying the groundwork for the ongoing unmanned factory.
Features
Realize automatic detection, grasping, feeding and dividing of the frame.
Realize unmanned feeding, refueling without stopping, etc.
Can meet the different requirements of frames, strong compatibility.
Visual inspection, pick out defective products,
Cache 70 sets of frames to meet the non-stop refueling.
Can be manual refueling, compatible with AGV car automatic refueling
Specifications
| Item | Value |
| Long frame | 1650-2520(mm) |
| Short frame | 990-1450(mm) |
| Cycle time | ≤16s |
| Compatible B-side frame size | 30-35(mm) |
| Power requirement | AC380V±5%，3P+1N+1PE，20A，50/60HZ |
| Power | 1 5kW |
| Air pressure | 0.6-0.8(MPa) |
| Noise | ≤70dB |
| Dimension(Lx W x H) | 6000*5000*4000(mm) |
| Weight | 2500kg |
