Stock Code: 000821
Menu
Functionality
Change time: ≤10min
Sand belt service cycle: ≥30000 times
Accuracy: ±1mm
Noise: ≤80dB
Features
Servo motor and synchronous belt drive, linear guide to ensure accurate and smooth operation.
Automatic control of equipment, operation process without personnel intervention.
The four corners are filed at the same time, and the four corners are driven by the motor.
Sand belt fast change structure, quick and convenient replacement.
Smooth section after filing corers, will not cause damage to the glass.
Specifications
| Item | Value |
| Compatible module size | length: 1700-2550(mm); width: 990-1450(mm) |
| Feeding method | (LEL) |
| Compatible module waveform range | 0-5(mm) |
| Compatible module thickness | 4-10(mm) |
| Tape specification | width: 30-40(mm); thickness: 0.06-0.10(mm) |
| Applicable edge type | Full edge double glass module, the length of tape head at the end is ≥50mm |
| Power | <8kW |
| Power requirement | 380V，50Hz，AC±5% |
| CDA | 0.6-0.8 (MPa)，300L/min |
| Dimension(L x W x H) | 4200*2500*2100(mm) |
