Functionality
Module positioning accuracy: ±1mm
Alignment: four side alignment
Change paper protector time: ≤180s
Change over time: 60cell<–>72cell one button switch
Normal<–>half-cut module<30min/1person
Operation mode: Auto/ Manual
Noise: ≤60dB
HMI: Chinese/ English mode
Features
The overall structure consists of alignment and conveyor unit, a corner protector inserting system and vacuum system.
Servo feeding automatic switching, to ensure module entering and exiting, saves cycle time.
Paper protector inserts automatically and then folds along the crerses.
Touch screen interface for changing module specifications, manual operation type, alarm information and other parameter setting.
Specifications
| Item | Value |
| Model | SC-CG25-CS-01 |
| Compatible module size | 长length: 1650-2550(mm);宽 width: 990-1450(mm) |
| Cycle time | ≤20s |
| Air pressure | 0.5-0.7(MPa) |
| Power | 8kW |
| Dimension(LxWxH) | 4150*1860*2000(mm) |
| Weight | 2800kg |
| Frame height | 30-45(mm) |
| Protector material | tri-wall corrugated paper, kraft paper |
| Protector thickness | corrugated paper 1+0.2(mm), kraft paper 0.3-0.5(mm) |
| Protector storage number | ≤500pcs |
